CP PLUS PoE Switch 10 Ports with 8 PoE Ports + 2 Gigabit Uplink Ports (CP‑DNW‑HPU8G2‑96‑V3)

High-Performance 8-Port PoE Switch with Gigabit Uplinks

The CP-DNW-HPU8G2-96-V3 is a 10-port unmanaged PoE Ethernet switch designed for powering and networking IP devices such as surveillance cameras, VoIP phones, and access points. It combines stable data transmission, reliable power delivery, and robust protection features to support small and medium CCTV setups or business networks.

🔑 Key Features

• 🏷️ Ports:

  • 8 PoE ports (10/100 Mbps) to power PoE devices directly over Ethernet.

  • 2 Gigabit uplink ports (1000 Mbps) for high-speed network connection.

• 🔌 PoE Power:

  • Supports IEEE802.3af/at PoE standards with up to 96 W total PoE budget.

  • Each PoE port can deliver up to 30 W to connected devices.

• ⚡ Performance:

  • 5.6 Gbps switching capacity and packet forwarding rate ~4.166 Mpps for smooth, uninterrupted data flow.

  • 448 K packet buffer for enhanced performance under load.

• 🛡️ Protection & Reliability:

  • Built-in ESD (8 kV air / 6 kV contact) and surge protection safeguards the switch and connected devices.

  • PoE Watchdog support helps restart unresponsive PoE devices automatically.

• 📍 Flexible Installation:

  • Supports plug-and-play setup, wall mount, or desktop installation.

  • Transmission up to 100 m over standard Ethernet cabling with extended options for longer distances.

• 🌐 Standards Supported:

  • IEEE 802.3, 802.3u, 802.3ab, and flow control (802.3x).
